Inductive Proximity Sensor M5 – NPN – NO

Description

This Inductive Proximity Sensor M5 – NPN – NO is widely used in the automatic control industry for detecting, controlling, and noncontact switching. When the proximity switch is close to some target object, it will send out a control signal.

There are many applications that these Inductive Sensors can be used such as General machines, paper making, light industry for limiting stations, orientation taking count, speeding trials, Laser, Plasmas, CNC Routers and etc.

With an M5x 30mm threaded body, this sensor can be easily adapted for our Plates and Brackets.  For the CNC Router application, this sensor can also be used with our most popular controllers such as xPRO V5

These Inductive sensors can be paired with many Plates and Brackets that we offer allowing many mounting options on the V-Slot Profile – 20 series.

Specification:

Operational Voltage: 12-24V DC
Thread Size: M5
Thread Length: 30mm
Model Number: LJ5A3-1-Z/BX
Transistor Type: NPN
Contact Type: Normally Open
Sensing Distance: 1mm±10%
Standard Detection: Iron 5x5x1mm
Detection Object: Magnetic Metal
Response Frequency: DC:0.5kHz AC:25Hz

Pro Tip:

For a 90-Degree mounting on a V-Slot Profile – 20 series, we recommend pairing the inductive switches to 1x M5 Drop-In Tee Nut and 1x M5x8mm Low Profile Screw.
