FF10 Floating Ball Screw Support With Clip
The FF10 floating ball screw support is used to support the end of the ball screw assembly and is secured with a clip. This support is commonly used in the SFU1204 ball screws and is compatible with our M4 Button Head Screws.
Call for price
US Warehouse
All products available on the website shipped from our US Warehouse.
Secure Payments
We do not store credit card details nor have access to your credit card information.
Description
FF10 Floating Ball Screw Support With Clip – Smooth and Stable Linear Actuation
The FF10 Floating Ball Screw Support with Clip is a reliable and efficient solution for achieving precise linear actuation in automation equipment. Designed to eliminate vibration, backlash, and position drift, this support ensures stable and accurate positioning in CNC machines, pick-and-place robots, and other motion control systems.
Specifically developed for 12mm ball screws like the SFU1204, the FF10 features a rigid construction that eliminates play and enables smooth rotational actuation. This makes it an ideal choice for precision equipment where accuracy is crucial. The support can be easily integrated into custom builds thanks to its reliable flange mounting capability and compatibility with M3 button head screws.
For a hassle-free positioning solution, consider our ball screw actuator kits that provide matched components for plug-and-play simplicity. Trust the FF10 to meet the demands of your precision projects.
Key Features:
- Clip-secured Design: Ensures stability and prevents vibration, backlash, and position drift for precise linear actuation.
- Rigid Construction: Specifically designed for 12mm ball screws, the FF10 eliminates play and enables smooth and accurate movements.
- Flange Mounting Capability: Easy integration into systems with reliable flange mounting, compatible with M3 button head screws.
Specifications:
- Collar Width:
- Mounting Holes: M3
- Compatible Ball Screws: SFU1204
- Mounting: Flange
Technical Drawing:
Applications:
The FF10 Floating Ball Screw Support with Clip can be used in various applications. One example is to mount a SFU1204 Ball Screw using an FK10 Floating Ball Screw Support and a DSG12H Ball Nut Housing on a Gantry Plate. For all the parts required for a ball screw setup, check out our full 12mm Ball Screw Kits.
Additional information
| Weight | .1 kg |
|---|---|
| Dimensions | 4 × 4 × 1 cm |
